Airtac GTFC Air Filter Regulator Combination GTFC20006LN
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series Filter Regulator Lubricator (FRL) Unit GTFC20006LN Technical Details
- Model: GTFC20006LN
- Type: Compact 2-stage combination unit (Filter + Regulator)
- Filtration grade: 5μm (with auto-drain)
- Pressure regulation range: 0.05–0.9 MPa
- Maximum flow rate: 2,000 L/min (ANR)
- Port size: PT3/8 (G3/8 optional)
- Pressure gauge: 1/8" BSP dial (0-1.6 MPa scale)
- Body material: Die-cast aluminum (anodized finish)
- Operating temperature: 5℃ to 60℃ (non-freezing)
- Condensate drain: Semi-automatic float type
- Weight: 1.25 kg (with bracket)
- Dimensions: 160mm(W) × 135mm(H) × 98mm(D)
- Seal compatibility: Compatible with ISO VG32 turbine oil
- Pressure adjustment knob: Lockable rotary type with ±2% accuracy
Modular FRL unit combining 40μm pre-filter and precision pressure regulation, featuring a corrosion-resistant aluminum housing with integrated mounting bracket. The dual-chamber design maintains stable output pressure (±0.02 MPa fluctuation) under dynamic load changes. Equipped with a manual bypass lever for emergency operation and a visible oil level window for lubricator models (when paired).
- Centralized pneumatic control systems in assembly lines
- CNC machine tool air preparation systems
- Packaging machinery pressure stabilization
- Industrial robot end-effector air supply
- Semiconductor manufacturing clean air supply
Installation guidelines:
Mount vertically with arrow marking aligned to airflow direction (→).
Maintain 50mm clearance below drain port for maintenance access.
Replace filter element every 4,000 operational hours or when pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GTFC20006LN |
| Port Size | PT1/8 |
