Airtac GTFC Air Filter Regulator Combination GTFC20006LNWK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series Filter Regulator Lubricator (FRL) Unit GTFC20006LNWK Specifications
- Model: GTFC20006LNWK (Triple Unit: Filter + Regulator + Lubricator)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–0.99 MPa
- Maximum flow: 3,500 L/min (ANR)
- Filter element: 40μm sintered bronze
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Lubricator oil capacity: 1.2cc (adjustable drip feed)
- Housing material: Die-cast aluminum (anodized finish)
- Seal material: NBR + Fluororubber hybrid
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.25kg (with full oil reservoir)
- Dimensions: 198mm(H) × 98mm(W) × 152mm(D)
- Mounting: Bracket slot for 40mm rail or panel screws
Integrated FRL unit combining 3-stage air preparation: mechanical filtration (with manual drain), precision pressure regulation with lockable knob, and visual oil-feed control. Features anti-clogging vortex separator design and corrosion-resistant bowl. Includes safety pressure relief valve and bowl guard.
- Pneumatic production line main air supply conditioning
- CNC machine tool pneumatic systems
- Automated assembly line actuator clusters
- Packaging machinery compressed air treatment
- Industrial robot end-effector support systems
Installation protocol:
Install vertically with arrow mark upward, 300mm downstream from compressor.
Maintain 50cm clearance below drain port. Lubricator requires ISO VG32 or
equivalent oil. Replace filter element every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | GTFC20006LNWK |
| Port Size | PT1/8 |
