Airtac GTFC Air Filter Regulator Combination GTFC20006LWK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006LWK FRL Combination Unit Specifications
- Model: GTFC20006LWK
- Type: 2-in-1 Filter Regulator Lubricator (Compact Series)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 3,200 L/min
- Filter rating: 40μm (5μm optional element)
- Adjustable pressure range: 0.05–0.85 MPa
- Oil droplet size: 1/8 turn adjustment (MIST 0~5 cc/min)
- Body material: Die-cast aluminum (anodized surface)
- Seal material: NBR + Polycarbonate
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.8 kg
- Dimensions: 200mm(W) × 165mm(H) × 82mm(D)
- Drain type: Manual float drain with anti-splash shield
- Pressure gauge: 63mm dial (MPa/psi dual scale)
Modular FRL unit with integrated pressure adjustment knob and visual oil-feed window. Features dual-chamber filter bowl with sediment visibility and impact-resistant polycarbonate cover. The regulator includes a tamper-proof lock ring and zero-adjustment knob safety feature. Pre-lubricated for 10,000 cycles maintenance-free operation.
- Plastic injection molding machine air preparation
- CNC machining center tool changers
- Automated assembly line pneumatic circuits
- Food packaging equipment (using food-grade lubricant)
- Textile machinery compressed air conditioning
Installation protocol:
Mount vertically with arrow aligned to airflow direction. Maintain 50mm clearance below bowl for drainage.
Pre-charge lubricator with ISO VG32 oil before operation. Replace filter element after 2,000 hours or when pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GTFC20006LWK |
| Port Size | PT1/8 |
