Airtac GTFC Air Filter Regulator Combination GTFC20006SNWK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20006SNWK FRL Combination Unit Specifications
- Model: GTFC20006SNWK
- Type: Filter Regulator + Lubricator (2-stage combination)
- Port size: PT3/8 (G3/8 optional)
- Max operating pressure: 1.5 MPa
- Filtration rating: 5 μm (40μm optional with mesh upgrade)
- Pressure adjustment range: 0.05–0.85 MPa
- Oil cup capacity: 180 cm³ (transparent polycarbonate)
- Body material: Aluminum alloy (A6063-T5)
- Seal material: NBR + Fluororubber hybrid
- Temperature range: -20℃ to 70℃ (non-freezing conditions)
- Flow rate: 3,500 Nl/min (at 0.7 MPa)
- Weight: 1.25 kg (dry, without oil)
- Dimensions: 198mm(H) × 140mm(W) × 82mm(D)
- Pressure gauge: 1/8" BSPT dial type (0-1.0 MPa scale)
- Drip rate adjustment: 3-5 drops/minute (calibrated at 0.5 MPa)
Modular FRL unit combining precision filtration (60% water removal efficiency) and pressure stabilization (±0.02 MPa regulation accuracy). Features anti-clogging sintered bronze filter element and corrosion-resistant anodized finish. Integrated bypass valve allows continuous operation during element replacement.
- CNC machine tool pneumatic systems
- Automated assembly line actuators
- Plastic injection molding machines
- Food packaging equipment (food-grade oil compatible)
- Railway braking systems (with vibration-resistant upgrade)
Maintenance protocol:
Replace filter element every 2,000 operational hours (or when pressure drop exceeds 0.1 MPa).
Use ISO VG32 turbine oil for lubrication. Drain condensate daily in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GTFC20006SNWK |
| Port Size | PT1/8 |
