Airtac GTFC Air Filter Regulator Combination GTFC20008LK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20008LK FRL Combination Unit Specifications
- Model: GTFC20008LK
- Type: 2-in-1 Air Treatment Unit (Filter Regulator)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 3,500 L/min
- Filter rating: 40 μm (5 μm optional element)
- Pressure gauge: 1/8" BSP dial type (0-1.6 MPa)
- Adjustment knob: Lockable rotary design
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR + POM composite
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.68 kg
- Dimensions: 178mm(L) × 85mm(W) × 132mm(H)
- Drain type: Manual float drain
- Mounting: Bracket slot (compatible with ISO 4414)
Modular air preparation unit combining precision filtration and pressure regulation. Features dual-chamber filter bowl with debris trap and anti-reverse flow design. The integrated regulator maintains ±0.02 MPa stability under fluctuating loads. Bowl guard protects against accidental impacts.
- Pneumatic production line manifolds
- CNC machine tool air supply systems
- Industrial robot end-effector controls
- Packaging machinery pressure management
- Semiconductor manufacturing equipment
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below drain port for maintenance.
Pre-charge regulator before system startup to prevent diaphragm damage.
| Property | Property Value |
|---|---|
| sku | GTFC20008LK |
| Port Size | PT1/4 |
