Airtac GTFC Air Filter Regulator Combination GTFC20008LNK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20008LNK Filter Regulator Lubricator (FRL) Unit Specifications
- Model: GTFC20008LNK
- Type: Compact 3-in-1 air preparation unit (Filter + Regulator + Lubricator)
- Filter rating: 5μm particulate removal
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Maximum flow: 3,500 L/min (Cv value: ~2.0)
- Port size: PT3/8 (BSPP thread)
- Body material: Anodized aluminum alloy
- Pressure gauge: 1/8" dial type (0-1.6 MPa range)
- Drain type: Semi-automatic float drain
- Temperature range: -20℃ to 60℃ (non-freezing conditions)
- Lubricator capacity: ~200ml (oil cup)
- Weight: 1.2kg (with oil)
- Dimensions: 200mm(H) × 150mm(W) × 100mm(D)
- Optional accessories: Bracket kit (MBT-12), pressure gauge protector
Modular FRL unit featuring triple-stage air treatment: mechanical water separation (60% efficiency), precision pressure regulation (±0.2MPa stability), and adjustable oil mist lubrication (3-5 drops/min). Integrated bypass design maintains airflow during maintenance. Equipped with anti-clogging sintered bronze filter element and impact-resistant polycarbonate bowl.
- Pneumatic tool air supply systems
- CNC machine pneumatic circuits
- Assembly line actuator controls
- Packaging machinery air preparation
- Robotic end-effector support systems
Maintenance protocol:
Drain condensate daily via push-button release. Replace filter element every 2,000 operational hours.
Use ISO VG32 pneumatic oil. Install vertically with arrow mark aligned to airflow direction.
| Property | Property Value |
|---|---|
| sku | GTFC20008LNK |
| Port Size | PT1/4 |
