Airtac GTFC Air Filter Regulator Combination GTFC20008SNK
$55.80
Regular price
$63.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GTFC20008SNK
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. This product belongs to the GA200 series short-type PC bowl configuration, inheriting all characteristics of the GA200 series while incorporating these distinctive features:
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
Maintenance tip:
Replace filter element every 6,000 operating hours or when pressure drop exceeds 0.1 MPa.
Always depressurize system before rotating the regulator knob.
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC20008SNK Filter Regulator Lubricator (FRL) Unit Specifications
- Model: GTFC20008SNK
- Type: 2-stage combination unit (Filter + Regulator)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 3,500 L/min (ANR)
- Filter grade: 5 μm (auto-drain version)
- Pressure gauge: 1/8" dial type (glycerin-filled)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: HNBR rubber (-20℃ to 80℃)
- Weight: 1.65 kg ±5%
- Dimensions: 200mm(H) × 140mm(W) × 90mm(D)
- Installation: Bracket mounting or direct piping
Modular FRL unit combining 40μm pre-filter and precision pressure regulator, featuring manual bypass lever for emergency operation. The bowl guard design meets ISO 4414 safety standards. Optional lubricator can be added via side port (M5 thread).
Typical Applications:
- Centralized pneumatic systems in CNC machinery
- Plastic injection molding air preparation
- Automated assembly line pressure control
- Food processing pneumatic circuits (oil-free version available)
- Railway brake air supply systems
Maintenance tip:
Replace filter element every 6,000 operating hours or when pressure drop exceeds 0.1 MPa.
Always depressurize system before rotating the regulator knob.
Configuration:
- Upstream filter protects regulator from particulates
- Regulator outlet pressure adjustable via locking knob
- Drain valve operates at 0.07 MPa differential pressure
- Pressure relief vent: Ø4mm silencer port
| Property | Property Value |
|---|---|
| sku | GTFC20008SNK |
| Port Size | PT1/4 |
