Airtac GVF Vacuum Filter GVF20006
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF Vacuum Filter GVF20006 Technical Specifications
- Model: GVF20006
- Type: Inline vacuum filter with auto-drain
- Port size: PT1/4 (G1/4 optional)
- Flow capacity: 300 L/min
- Filtration grade: 5 μm (98% efficiency)
- Max vacuum pressure: -100 kPa
- Body material: Anodized aluminum alloy
- Filter element: Stainless steel mesh + glass fiber
- Operating temperature: -20℃ to 60℃
- Weight: 320 g ±5g
- Dimensions: 78mm(L) × 50mm(W) × 92mm(H)
- Drain type: Manual/auto dual-mode
- Bowl capacity: 15 mL
- Thread torque: 1.5-2.0 N·m
High-efficiency coalescing filter designed for vacuum line protection, featuring triple-stage filtration (mechanical separation, centrifugal force, and depth filtration). The corrosion-resistant bowl allows visual contamination monitoring with chemical-resistant PC material. Integrated silencer reduces exhaust noise by 15 dB(A).
- Vacuum gripping systems in pick-and-place robots
- Medical suction equipment filtration
- PCB handling vacuum generators
- Glass processing vacuum chucks
- Packaging machine vacuum conveyors
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02 MPa.
Always install vertically with arrow marking facing downstream. Clean bowl weekly using
non-ionic surfactant (pH 6-8).
| Property | Property Value |
|---|---|
| sku | GVF20006 |
| Port Size | PT1/8 |
