Airtac GVF Vacuum Filter GVF20006J
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF20006J Vacuum Filter Technical Details
- Model: GVF20006J (GVF Series)
- Type: Inline vacuum filter with automatic drain
- Filtration grade: 40μm (98% efficiency)
- Maximum flow rate: 200 L/min
- Port size: PT1/4 (G1/4 thread equivalent)
- Body material: Anodized aluminum alloy
- Filter element: Hydrophobic polyester fiber
- Operating temperature: 5℃ to 60℃
- Max working pressure: 1.0 MPa
- Weight: 200g ±5%
- Dimensions: 80mm(L) × 45mm(W) × 45mm(H)
- Drain type: Float-operated automatic
- Bowl material: Polycarbonate (impact-resistant)
- Seal material: NBR rubber
High-efficiency vacuum line protector featuring triple-stage filtration (deflector, mesh screen, and depth filtration). The transparent bowl allows visual contamination monitoring, while the zero-pressure-loss automatic drain prevents liquid accumulation. Designed for continuous operation with 360° mounting capability.
- Vacuum gripping systems in pick-and-place robots
- Medical suction equipment filtration
- Semiconductor wafer handling vacuum lines
- Food packaging vacuum seal systems
- Printing press sheet feeding mechanisms
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02MPa.
Clean bowl weekly using non-corrosive solvents. Install vertically for optimal drainage.
| Property | Property Value |
|---|---|
| sku | GVF20006J |
| Port Size | PT1/8 |
