Airtac GVF Vacuum Filter GVF20006W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF20006W Vacuum Filter Technical Details
- Model: GVF20006W
- Type: Inline vacuum filter with auto-drain
- Filtration rating: 5 μm (microns)
- Flow capacity: 200 L/min @ 0.5 MPa
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: -100 kPa to 1.0 MPa
- Temperature range: -10℃ to 60℃
- Filter element material: Hydrophobic polyester fiber
- Housing material: Anodized aluminum alloy
- Drain type: Manual/auto float drain (optional)
- Weight: 185g ±5g
- Dimensions: 62mm(D) × 82mm(H) × 45mm(W)
- Thread depth: 12mm (both ports)
- Pressure loss: ≤0.02 MPa @ max flow
- Moisture separation efficiency: ≥95% @ 20℃/60% RH
High-efficiency coalescing filter designed for vacuum line protection, featuring dual-stage filtration with mechanical barrier and depth loading. The anti-corrosion aluminum body incorporates a transparent bowl (optional) for visual contamination monitoring. Optimized for pulsating vacuum environments with surge-resistant design.
- Vacuum gripper systems in pick-and-place robots
- Medical suction equipment filtration
- Semiconductor wafer handling vacuum lines
- Packaging machine vacuum generators
- 3D printer bed adhesion systems
- Laboratory vacuum drying setups
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.03 MPa.
Always install vertically with arrow marking pointing toward vacuum pump.
Use thread sealant on male ports (PTFE tape not recommended).
| Property | Property Value |
|---|---|
| sku | GVF20006W |
| Port Size | PT1/8 |
