Airtac GVF Vacuum Filter GVF20008
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF20008 Vacuum Filter Technical Details
- Model: GVF20008 (GVF Series)
- Type: Inline vacuum filter with auto-drain
- Port size: PT1/8 (BSP 1/8") dual female threads
- Max flow rate: 300 L/min (at 0.6 MPa)
- Filtration grade: 5 μm (98% efficiency)
- Max vacuum pressure: -100 kPa
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM)
- Operating temp: 0℃ to 60℃ (non-freezing)
- Weight: 185 g ±5g
- Dimensions: 78mm(L) × 34mm(Ø) × 94mm(H with bracket)
- Drain type: Manual/auto hybrid drainage
- Bypass valve: Integrated pressure relief
High-efficiency particulate filter designed for vacuum line protection, featuring triple-stage filtration with cyclone separation, fiber mesh, and sintered filter elements. The corrosion-resistant construction includes a visible contamination indicator window and tool-free bowl removal. Compatible with ISO 8573-1 air quality standards.
- Vacuum pick-and-place systems in SMT assembly
- Medical suction equipment filtration
- Lithium battery production dry rooms
- Automated packaging machine end effectors
- Semiconductor wafer handling robots
Maintenance protocol:
Replace filter element every 2,000 operational hours or when red indicator pops up.
Always install vertically with arrow mark facing vacuum pump direction.
Drain condensate daily in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GVF20008 |
| Port Size | PT1/4 |
