Airtac GVF Vacuum Filter GVF200C06J
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200C06J Vacuum Filter Technical Specifications
- Model: GVF200C06J
- Series: GVF Compact Vacuum Filter
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: BSPP (Parallel)
- Filtration rating: 40μm (multi-stage filtration)
- Max pressure: 0.9 MPa (130 psi)
- Flow capacity: 200 L/min (ANR)
- Weight: 280g ±5g (with mounting bracket)
- Dimensions: 76mm(L) × 50mm(W) × 98mm(H)
- Body material: Anodized aluminum alloy
- Filter element: Stainless steel mesh + synthetic fiber
- Operating temperature: -10℃ to 60℃ (14℉ to 140℉)
- Drain type: Manual drain cup (transparent polycarbonate)
- Bowl capacity: 12ml
- Installation orientation: Vertical/horizontal (bowl downward)
- Certification: RoHS compliant
High-efficiency coalescing filter with multi-stage separation technology, featuring a visible contamination indicator window. The dual-layer filtration system combines mechanical interception and adsorption filtration, specifically engineered for vacuum pump protection. Includes anti-suckback design to prevent fluid re-entry during system shutdown.
- Vacuum gripping systems in PCB handling equipment
- Medical device manufacturing cleanrooms
- Automated packaging line suction cups
- Semiconductor wafer processing tools
- 3D printer bed adhesion systems
- Laboratory vacuum desiccators
Maintenance protocol:
Replace filter element after 2,000 operational hours or when liquid reaches 80% of bowl capacity.
Always depressurize system before rotating drain cup (quarter-turn release mechanism).
| Property | Property Value |
|---|---|
| sku | GVF200C06J |
| Port Size | PT1/8 |
