Airtac GVF Vacuum Filter GVF200C08
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF Vacuum Filter GVF200C08 Technical Specifications
- Model: GVF200C08
- Type: Compact vacuum filter with auto-drain
- Filtration grade: 40μm (mesh size)
- Maximum flow capacity: 200 L/min
- Port size: PT1/8 (G1/8 optional)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Operating pressure range: -100kPa to 0.8MPa
- Temperature range: -5℃ to 60℃ (operating), -20℃ to 80℃ (storage)
- Weight: 280g ±5g
- Dimensions: 98mm(L) × 52mm(W) × 72mm(H)
- Drain type: Semi-automatic float drain
- Filter element: Sintered stainless steel (replaceable)
- Protection rating: IP40
- Mounting orientation: Vertical installation recommended
High-efficiency coalescing filter designed for vacuum line protection, featuring dual-stage filtration with mechanical separation and depth filtration. The corrosion-resistant aluminum body contains a visible bowl for condensate monitoring. Integrated silencer reduces exhaust noise by 15dB(A). Compatible with ISO 5599-1 mounting standards.
- Vacuum pick-and-place systems in SMT assembly lines
- Medical device manufacturing vacuum circuits
- Semiconductor wafer handling equipment
- Automated packaging machine suction cups
- 3D printer vacuum bed systems
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02MPa.
Drain bowl should be emptied daily in high-humidity environments. Use only compatible AirTAC
replacement parts (P/N: GVFC-40M) to maintain ISO 8573-1 Class 4 air quality.
| Property | Property Value |
|---|---|
| sku | GVF200C08 |
| Port Size | PT1/4 |
