Airtac GVF Vacuum Filter GVF200C08JW
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200C08JW Vacuum Filter Technical Details
- Model: GVF200C08JW
- Series: GVF200 Compact Series
- Port size: G1/8 (ISO228 standard)
- Filtration grade: 0.3 μm (microns)
- Maximum flow rate: 300 L/min
- Operating pressure: -100 kPa to 0.8 MPa
- Temperature range: -20℃ to 60℃
- Housing material: Anodized aluminum alloy
- Filter element: Hydrophobic PTFE membrane
- Bowl material: Transparent polycarbonate
- Weight: 215 g ±5g
- Dimensions: 80mm(H) × Φ46mm (body diameter) × 62mm (base width)
- Drain type: Manual drain plug (M5 thread)
- Installation orientation: Vertical/horizontal compatible
- Vibration resistance: ≤10 Hz, 1.5mm amplitude
High-efficiency coalescing filter with moisture separation capability, featuring a triple-stage filtration process (cyclonic separation, mesh screen, and membrane filtration). The anti-corrosion aluminum body withstands aggressive environments while the transparent bowl allows visual contamination monitoring. Includes built-in silencer for noise reduction below 75 dB(A).
- Vacuum pick-and-place systems in SMT assembly lines
- Medical suction equipment filtration
- Lithium battery manufacturing vacuum chambers
- Automated packaging machine vacuum generators
- Semiconductor wafer handling robots
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds -15 kPa.
Clean bowl weekly using IPA solution (isopropyl alcohol 70%+). Always depressurize system
before servicing.
- Auto-drain upgrade kit available (GVF-ADK200)
- Optional metal bowl variant for high-temperature environments
- Stackable design allows series connection with pressure regulators
| Property | Property Value |
|---|---|
| sku | GVF200C08JW |
| Port Size | PT1/4 |
