Airtac GVF Vacuum Filter GVF200C08W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200C08W Vacuum Filter Technical Specifications
- Model: GVF200C08W
- Type: Inline vacuum filter with auto-drain
- Flow capacity: 200 L/min (at 0.6MPa)
- Filtration grade: 40μm (98% efficiency)
- Port size: PT1/8 (BSP1/8 parallel thread)
- Body material: Aluminum alloy (anodized surface)
- Filter element: Sintered stainless steel (SS304)
- Operating pressure: -100kPa to 1.0MPa
- Temperature range: -20℃ to 60℃ (non-freezing)
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 42mm(H)
- Drain type: Manual/auto dual-mode
- Bowl capacity: 15ml
- Seal material: Fluororubber (FKM)
- Pressure loss: ≤0.02MPa (at rated flow)
High-efficiency vacuum line protector featuring dual-layer filtration with cyclone separation technology. The zinc-nickel plated bowl resists chemical corrosion, while the transparent polycarbonate window allows visual contamination monitoring. Integrated silencer reduces exhaust noise by 15dB(A).
- Vacuum gripping systems in CNC machining centers
- Semiconductor wafer handling equipment
- Medical device assembly vacuum lines
- Automotive painting robot end effectors
- Food packaging machine suction cups
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.03MPa.
Lubricate O-ring with silicone grease (MIL-G-27617) during reassembly.
| Property | Property Value |
|---|---|
| sku | GVF200C08W |
| Port Size | PT1/4 |
