Airtac GVF Vacuum Filter GVF200N06
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200N06 Vacuum Filter Technical Specifications
- Model: GVF200N06
- Type: Vacuum generator integrated filter
- Port size: PT1/4 (NPT1/4 optional)
- Filtration grade: 5 μm (microns)
- Maximum flow rate: 200 L/min (Nl/min)
- Operating pressure range: -100 kPa to 0.8 MPa
- Temperature range: 5℃ to 60℃
- Housing material: Anodized aluminum alloy
- Filter element: Stainless steel mesh + synthetic fiber
- Seal material: NBR (Nitrile rubber)
- Weight: 480 g ±5%
- Dimensions: 98mm(L) × 62mm(W) × 98mm(H)
- Thread torque resistance: 15 N·m max
- Vacuum response time: ≤0.3 sec (at 0.5 MPa)
- Certification: RoHS compliant
High-efficiency vacuum filtration unit combining particle separation and vacuum generation, featuring a dual-stage filtration system with automatic drainage capability. The corrosion-resistant anodized surface and precision sintered metal filter ensure stable performance in humid environments. Designed for continuous operation with 0.1MPa minimum supply pressure requirement.
- Vacuum gripping systems in packaging machinery
- PCB handling in electronics manufacturing
- Medical device assembly with clean air requirements
- Automated material handling robots
- Printing press paper feeding mechanisms
- Glass panel transportation systems
Maintenance protocol:
Replace filter element every 2,000 operational hours or when vacuum efficiency drops 15%.
Always install vertically with arrow mark facing downstream. Use thread sealant on male ports.
Critical note:
Do not use with phosphate ester-based lubricants. Maintain ambient humidity below 80% RH
to prevent moisture accumulation in filter chamber.
| Property | Property Value |
|---|---|
| sku | GVF200N06 |
| Port Size | PT1/8 |
