Airtac GVF Vacuum Filter GVF200N08
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200N08 Vacuum Filter Technical Details
- Model: GVF200N08 (GVF Series)
- Type: Inline vacuum filter with manual drain
- Port size: PT1/8 (NPT1/8 optional)
- Max flow capacity: 200 L/min
- Filtration grade: 40μm (5μm optional element available)
- Operating pressure range: -100kPa to 0.8MPa
- Body material: Anodized aluminum alloy
- Seal material: Fluorine rubber (FKM)
- Temperature range: -10℃ to 60℃
- Weight: 280g ±5%
- Dimensions: 98mm(L) × 50mm(W) × 62mm(H)
- Bowl capacity: 15ml
- Thread engagement depth: 8mm minimum
High-efficiency coalescing filter designed for vacuum line protection, featuring dual-stage filtration with stainless steel mesh pre-filter and fiber element. The transparent polycarbonate bowl allows visual contamination monitoring. Anti-backflow design prevents liquid re-entry into system. Meets ISO 8573-1:2010 Class 4 standards.
- Vacuum gripper systems in pick-and-place robots
- Medical suction equipment filtration
- Semiconductor wafer handling vacuum lines
- Packaging machine vacuum generators
- Laboratory analytical instrument protection
Maintenance protocol:
Replace element when pressure drop exceeds 0.02MPa.
Drain accumulated liquid daily in high-humidity environments.
Use thread seal tape on male ports during installation.
| Property | Property Value |
|---|---|
| sku | GVF200N08 |
| Port Size | PT1/4 |
