Airtac GVF Vacuum Filter GVF200N08W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF200N08W Vacuum Filter Technical Details
- Model: GVF200N08W
- Type: Compact inline vacuum filter with auto-drain
- Port size: NPT1/8 (ISO G1/8 compatible)
- Operating pressure: -100 kPa to 0.7 MPa
- Max flow rate: 200 L/min (at 0.5 MPa)
- Filtration grade: 40μm (5μm optional with different filter element)
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM)
- Temperature range: -10℃ to 60℃
- Weight: 320g ±5g
- Dimensions: 98mm(L) × 52mm(W) × 82mm(H)
- Drain type: Manual/auto hybrid drainage
- Bowl capacity: 15ml
- Compliance: RoHS 2.0, REACH
High-efficiency coalescing filter designed for vacuum line protection, featuring dual-stage filtration with cyclonic pre-separation. The transparent polycarbonate bowl allows visual contamination monitoring. Anti-backflow design prevents liquid re-entrainment during pressure fluctuations.
- Vacuum pick-and-place systems in SMT assembly
- Medical suction device air purification
- Packaging machine vacuum grippers
- Laboratory vacuum chamber supply lines
- 3D printer bed adhesion systems
Installation protocol:
Mount vertically with arrow direction matching airflow. Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.02MPa. Use thread sealant on male ports - do not overtighten (recommended torque 12-15N·m).
| Property | Property Value |
|---|---|
| sku | GVF200N08W |
| Port Size | PT1/4 |
