Airtac GVF Vacuum Filter GVF30008W
2、Features minimal pressure drop, superior moisture separation efficiency, and oversized condensate reservoir capacity;
3、Available with selectable filtration precision: 5μm or 40μm;
4、Multiple bowl material options (PC, metal, nylon) adapt to diverse operating environments;
5、Optional fixed bracket mounting configuration for enhanced installation stability.
Category: Vacuum Filters | Brand: AirTAC | Series: GVF
AirTAC GVF30008W Vacuum Filter Technical Details
- Model: GVF30008W (Silver Series)
- Type: 2-stage vacuum filtration with automatic drain
- Filtration grade: 5μm primary + 0.3μm secondary
- Max flow capacity: 300 L/min @ 0.6MPa
- Port size: G1/8 (BSPP thread)
- Max vacuum level: -95kPa (710mmHg)
- Body material: Anodized aluminum alloy
- Filter element: Sintered stainless steel (SS316L)
- Operating temperature: -10℃ to 60℃ (non-freezing)
- Weight: 480g ±5% (with mounting bracket)
- Dimensions: 98mm(H) × 62mm(W) × 48mm(D)
- Drain type: Float-operated automatic discharge
- Pressure loss: ≤0.02MPa @ rated flow
- Compatibility: Works with all ISO 5599-1 vacuum generators
Professional-grade vacuum filtration system featuring dual-layer precision filtration and zero-air-loss drainage. The corrosion-resistant construction with aerospace-grade seals ensures 15,000+ hour service life in continuous operation. Integrated mounting slots allow 360° rotation for flexible plumbing configurations.
- PCB handling robots in electronics manufacturing
- Vacuum chuck systems for CNC machining centers
- Medical device assembly automation
- Glass panel transfer systems
- Food packaging suction grippers
- Semiconductor wafer handling equipment
Maintenance protocol:
Replace primary filter every 2,000 operating hours (visual inspection window included).
Always depressurize system before servicing. Compatible with AirTAC VF-5 cleaning fluid.
| Property | Property Value |
|---|---|
| sku | GVF30008W |
| Port Size | PT1/4 |
