Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10R
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10R Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK10R (Guided Parallel Type)
- Gripping Force: 24N at 0.5MPa
- Stroke per Jaw: 5mm
- Operating Pressure: 0.1-0.7MPa
- Port Size: M5x0.8 (Dual Acting)
- Repeat Accuracy: ±0.02mm
- Max Opening Speed: 100mm/s
- Guide Mechanism: Dual Linear Ball Bearings
- Piston Material: Hard Anodized Aluminum
- Seal Material: NBR (Oil Resistant)
- Ambient Temperature: -10℃ to 70℃
- Protection Class: IP54
- Weight: 0.28kg
- Dimensions: 60mm(L) × 34mm(W) × 35mm(H)
Precision parallel gripper with integrated linear guides and zero backlash design, featuring symmetrical force distribution and smooth operation. The hardened guide rails provide exceptional lateral rigidity for handling eccentric loads. Optimized air passage design reduces air consumption by 15% compared to conventional models.
- PCB component insertion machines
- Precision gear assembly systems
- Automated optical inspection (AOI) equipment
- Micro-motor rotor handling
- Pharmaceutical blister packaging lines
Operation tip:
For optimal performance with fragile components, maintain air pressure between 0.3-0.5MPa
and install a precision pressure regulator with 5μm filtration. Lubricate guide rails every
50,000 cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HFSK10R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
