Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK20
- Type: Dual-rail parallel motion gripper
- Gripping force: 28-42N (at 0.5-0.7MPa)
- Operating pressure: 0.1-0.7 MPa
- Stroke per jaw: 20mm (standard), customizable 10/15/30mm options
- Rail type: Precision ground steel with PTFE coating
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for push/pull action)
- Mounting: 4x M4 threaded holes (side/top mounting)
- Body material: Anodized aluminum alloy (A6063)
- Seal material: NBR (nitrile) rubber
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (standard), IP67 optional
- Weight: 450g ±5%
- Dimensions: 102mm(L) × 54mm(W) × 48mm(H)
High-precision parallel gripper with dual hardened steel rails ensuring minimal play during high-speed operations. Features symmetrical air pressure distribution channels for balanced gripping force. Integrated T-slot design allows direct mounting of sensors or accessories. Compatible with ISO-9409-1 mounting patterns.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Automotive fuel injector assembly
- 3C product testing equipment
- Precision bearing handling systems
Operational note:
Requires 5-10μm filtered air with ISO VG32 lubrication.
For maximum cycle rate (up to 180 cycles/min), maintain air pressure
above 0.4MPa and use shock absorbers for payloads over 1kg.
- HFD-M8N magnetic sensor (sold separately)
- AGP-20 adaptive grip pads (various durometers)
- MXT40 mounting bracket kit
| Property | Property Value |
|---|---|
| sku | HFSK20 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
