Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20B
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20B Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK20B
- Type: Guided parallel movement (double-acting)
- Gripping force: 28-85N (adjustable via 0.1-0.7MPa pressure)
- Stroke per jaw: 0-12mm (total opening 24mm)
- Operating pressure: 0.1-0.7 MPa
- Port size: M5x0.8 (dual ports for push/pull action)
- Repeatability: ±0.02mm
- Body material: Anodized aluminum alloy
- Guide rail: Hardened stainless steel (HRC58-62)
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Max sliding speed: 200mm/s
- Weight: 480g ±2%
- Dimensions: 85mm(L) × 42mm(W) × 34mm(H)
- Compatible rail types: HSR15 linear guide (sold separately)
Precision parallel gripper with integrated linear guides for ultra-stable part handling. Features zero-backlash adjustment mechanism and wear-compensation design. The dual piston structure ensures synchronized jaw movement, while T-slot mounting enables flexible integration. Requires filtered air (5-50μm) with ISO VG32 lubricant.
- CNC machine tool part loading/unloading
- PCB component insertion systems
- Pharmaceutical blister packaging lines
- Precision bearing assembly stations
- Automotive fuel injector handling
Mounting advice:
Align guide rails within 0.05mm parallelism tolerance. Apply lithium soap-based grease
to rail surfaces every 50km of travel. Use shock absorbers for payloads over 1.2kg.
| Property | Property Value |
|---|---|
| sku | HFSK20B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
