Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20R
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20R Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK20R
- Type: Guided parallel gripper (double-acting)
- Gripping force: 20N at 0.5MPa
- Stroke per jaw: 6mm (total opening 12mm)
- Operating pressure: 0.2–0.7 MPa
- Port size: M5x0.8 (dual ports for push/pull action)
- Body material: Anodized aluminum alloy
- Slide rails: Precision ground steel with self-lubricating bushings
- Repeat accuracy: ±0.01mm
- Temperature range: -10℃ to 80℃
- Protection rating: IP40
- Compatible rail models: SR15W/SR20W series
- Cycle life: 5 million operations
- Weight: 680g ±2%
- Dimensions: 120mm(L) × 45mm(W) × 34mm(H)
High-precision parallel gripper with integrated linear guides, engineered for stable gripping in automated assembly. Features zero-backlash motion through dual guide posts and hardened steel rails. The R-suffix model includes replaceable polyurethane finger pads (Shore A80) for delicate object handling. Requires dry compressed air with 25μm filtration.
- PCB component insertion machines
- Medical device micro-assembly
- Watch movement handling systems
- Automotive fuel injector production
- Semiconductor wafer cassette transfer
Installation note:
Mount using M4 screws on 60mm centers. For maximum accuracy,
pair with matching SR-series rails and calibrate using the
integrated alignment notches. Lubricate guide rods every
50,000 cycles with ISO VG32 hydraulic oil.
- HSF-MK20: Magnetic key for tooling plate alignment
- HFS-SP20: Spare seal kit (NBR + PTFE)
- ADP-5C: Compact air distribution block with built-in regulator
| Property | Property Value |
|---|---|
| sku | HFSK20R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
