Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK32B
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK32B Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK32B
- Type: Guided parallel gripper (double-acting)
- Bore size: Ø32mm
- Gripping force: 58N at 0.6MPa
- Stroke per jaw: 0-12mm (adjustable)
- Operating pressure: 0.2-0.7MPa
- Guide type: Dual hardened stainless steel linear rails
- Repeat accuracy: ±0.02mm
- Material: Aluminum alloy body with anti-corrosion treatment
- Seal material: Heat-resistant NBR
- Temperature range: -10℃ to 80℃
- Weight: 1.24kg
- Dimensions: 122mm(L) × 72mm(W) × 70mm(H)
- Mounting pattern: ISO 9409-1-50-4-M6 (standard)
- Air inlet: M5×0.8 (dual ports for push/pull operation)
- Shock absorption: Built-in rubber bumpers
High-rigidity parallel gripper with precision-ground guide rails, designed for stable gripping of medium-sized components. Features adjustable stroke limiters and zero-backlash movement through preloaded linear guides. Compatible with vacuum cups/magnetic adapters via 6×M4 threaded mounting points on jaw faces.
- CNC machine tool loading/unloading systems
- Precision electronic component assembly (PCB handling)
- Pharmaceutical blister packaging lines
- Automotive fuel injector manufacturing
- 3C product testing equipment
Operation tip:
For delicate objects, use 0.3-0.5MPa pressure with silicone jaw pads.
Lubricate guide rails every 500km travel distance using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | HFSK32B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
| Stroke | 22mm |
