Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK16B
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK16B Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK16B
- Type: Guided parallel gripper (double-acting)
- Bore size: Ø16mm
- Stroke: 10mm (standard), customizable 5-20mm
- Operating pressure: 0.1-0.7 MPa
- Max gripping force: 42N at 0.5MPa
- Repeat accuracy: ±0.02mm
- Guide mechanism: Precision linear ball bearings
- Body material: Anodized aluminum alloy
- Slide rail material: Stainless steel
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 60℃
- Weight: 480g ±2%
- Dimensions: 112mm(L) × 42mm(W) × 36mm(H)
- Port size: M5x0.8 (dual ports for bidirectional control)
- Response time: 0.1s (full stroke at 0.5MPa)
- Protection rating: IP54
High-precision guided gripper with integrated linear guides and wear-resistant components, designed for repetitive pick-and-place operations requiring micron-level accuracy. Features symmetrical force distribution and anti-rotation design for stable gripping of irregular shapes. Compatible with vacuum cups or custom jaws (optional jaw kits available).
- PCB component insertion machines
- Medical device assembly lines
- Precision gear handling systems
- Automotive fuel injector production
- 3C product testing equipment
- Silicon wafer transfer robots
Installation tip:
Use alignment jigs during mounting to ensure parallel installation.
Lubricate guide rails with ISO VG32 hydraulic oil monthly.
Maintain air supply dew point 15℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | HFTK16B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
