Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK16W
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK16W Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK16W
- Type: Guided parallel gripper (dual rail structure)
- Gripping force: 16N at 0.5MPa
- Stroke per finger: 0-6mm (adjustable)
- Operating pressure: 0.1–0.7 MPa
- Port size: M5 (1/8" NPT optional)
- Weight: 350g ±5%
- Dimensions: 98mm(L) × 48mm(W) × 36mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Repeat accuracy: ±0.02mm
- Maximum gripping speed: 100mm/s
- Mounting: 4x M4 threaded holes (depth 6mm)
High-precision guided gripper with dual linear rails for smooth parallel motion and minimal deflection. Features wear-resistant brass guides and dust-resistant seals. Ideal for delicate part handling with positional feedback capability through optional magnetic sensors (sensor slots pre-machined). Requires filtered lubricated air (ISO 8573-1 class 3.4.2).
- PCB component insertion in electronics assembly
- Medical device precision part handling
- Automated packaging of cosmetic products
- Robotic arm end-effector for small mechanical assemblies
- Laboratory sample handling systems
Operation tip:
For optimal performance, maintain air pressure stability (±0.02MPa) and
lubricate guide rails every 50,000 cycles using ISO VG32 turbine oil.
Adjust grip force via pressure regulator to prevent part deformation.
- Magnetic sensors: APSE-4M (gap detection ≤1.5mm)
- Mounting brackets: HFLQ-16 series
- Dust covers: DCF-16W (IP54 rating)
| Property | Property Value |
|---|---|
| sku | HFTK16W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
