Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK20N
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK20N Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK20N
- Type: Double-acting parallel gripper with integrated linear guide
- Gripping force: 20N @ 0.5MPa
- Stroke per jaw: 4mm (total opening 8mm)
- Operating pressure: 0.1-0.7 MPa
- Port size: PT1/8 (G1/8 optional)
- Guide mechanism: Dual sliding rail system
- Repeat accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 450g ±5%
- Dimensions: 160mm(L) × 60mm(W) × 40mm(H)
- Protection rating: IP40
- Compliance: ISO 6432 standard
Precision rail-guided gripper featuring zero backlash operation and ultra-stable clamping performance. The hardened steel linear guides provide exceptional lateral rigidity, making it ideal for high-accuracy positioning tasks. Includes built-in air cushioning for smooth operation up to 5 cycles/second.
- PCB component insertion machines
- Medical device assembly lines
- Optical lens handling systems
- Automated quality inspection stations
- Precision gearbox manufacturing
Installation note:
Mount using M4 screws on 140mm centers. Lubricate guide rails with ISO VG32 hydraulic oil during maintenance.
Maintain 0.3-0.5μm filtration for optimal seal life. Avoid side-load forces exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | HFTK20N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
