Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK25B
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK25B Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK25B
- Type: Rail-guided parallel gripper (double-acting)
- Gripping force: 15-25N (adjustable via pressure)
- Stroke per jaw: 0-6mm
- Operating pressure: 0.1-0.7 MPa
- Max speed: 150mm/s
- Repeat accuracy: ±0.02mm
- Body material: Aluminum alloy (anodized finish)
- Rail type: Dual linear guides with hardened steel rails
- Temperature range: -10℃ to 80℃
- Port size: M5×0.8 (dual ports for push/pull control)
- Mounting: 3×M4 threaded holes (bottom/top/side)
- Weight: 385g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 28mm(H)
- Seal material: Heat-resistant NBR rubber
- Shock resistance: 15G (3ms duration)
- Vibration resistance: 1.5mm amplitude (10-55Hz)
Precision rail-guided gripper with ultra-low friction design, featuring twin linear guides for smooth parallel motion. The hardened steel rails and dual ball bearing blocks ensure zero backlash during high-speed cycling. Optimized for micro-positioning tasks requiring micron-level repeatability, with IP54 protection against particulate contamination.
- PCB component insertion machines
- Medical device assembly lines
- Optical lens handling systems
- Watch movement manufacturing
- Precision gearbox assembly
- Silicon wafer transfer robots
Operation tip:
For optimal performance, use filtered air (5μm minimum) with ISO VG32 hydraulic oil mist lubrication (1 drop/1,000 cycles). Avoid lateral overload exceeding 5N. Align guide rails within 0.1mm parallelism tolerance during installation.
Critical note:
Requires daily rail cleaning with non-woven wipes and monthly re-lubrication with MOBILUX EP2 grease. Do NOT disassemble bearing blocks - contact certified technicians for maintenance.
| Property | Property Value |
|---|---|
| sku | HFTK25B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
