Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK25W
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK25W Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK25W
- Type: Guided parallel gripper (double-acting)
- Bore size: Φ25mm
- Operating pressure: 0.2–0.7 MPa
- Max stroke: 15mm
- Guide type: Linear ball bearing rail
- Gripping force: 110N@0.5MPa
- Repeat accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Seal material: NBR/HNBR optional
- Temperature range: -10℃ to 80℃ (NBR) / -10℃ to 150℃ (HNBR)
- Weight: 1.25kg
- Dimensions: 146mm(L) × 55mm(W) × 45mm(H)
- Mounting: 4×M5 threaded holes (side mounting)
- Air port: M5×0.8 (standard) / NPT1/8 optional
- Protection rating: IP54
Precision guided gripper with integrated linear rails for stable parallel motion, featuring zero backlash adjustment mechanism for precise centering. The hardened guide rail system provides 3x longer service life compared to standard bush-guided models. Compatible with vacuum suction cup adapters and various jaw configurations.
- CNC machine tool part loading/unloading
- Electronics PCB handling systems
- Medical device assembly lines
- Automotive component sorting
- Glass panel transfer systems
Operation tip:
For delicate object handling, use 0.3-0.4MPa operating pressure with silicone
cushion jaws. Lubricate guide rails every 500,000 cycles using ISO VG32
turbine oil.
| Property | Property Value |
|---|---|
| sku | HFTK25W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
