Airtac HFTKL Guided Parallel Type Pneumatic Gripper HFTKL20F
Type: Rail-Guided Parallel Pneumatic Gripper
Brand: AirTAC
Series: HFTKL
AirTAC HFTKL20F Guided Parallel Pneumatic Gripper Specifications
- Model: HFTKL20F
- Type: Guided parallel gripper with linear guide rails
- Gripping force: 30-150N (adjustable via air pressure)
- Stroke per finger: 0-20mm
- Operating pressure: 0.1-0.7 MPa
- Guide mechanism: Dual linear ball bearing slides
- Repeat accuracy: ±0.02mm
- Port size: M5 (1/8")
- Material: Aluminum alloy body, hardened steel guide rails
- Temperature range: -10℃ to 80℃
- Weight: 480g ±5%
- Dimensions: 92mm(L) × 42mm(W) × 34mm(H)
- Seal type: NBR rubber (oil-resistant)
- Max operating speed: 100mm/s
- Mounting: 4x M4 threaded holes (depth 6mm)
Precision parallel gripper with integrated linear guides for ultra-stable part handling. Features zero-backlash movement and wear compensation mechanism. The dual-cylinder design ensures synchronized finger movement, ideal for delicate component manipulation. Compatible with ISO 9400-1 mounting interfaces.
- PCB component insertion machines
- Precision bearing assembly systems
- Pharmaceutical blister packaging lines
- Automotive fuel injector handling
- 3C product testing equipment
Operation note:
Requires 5-50μm filtered air with lubrication (ISO VG32 recommended).
Install shock absorbers when gripping fragile items at maximum speed.
Periodic rail lubrication interval: 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | HFTKL20F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | 18mm |
