Airtac HRQ Rotary Cylinder HRQ100
$314.75
Regular price
$322.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HRQ100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HRQ Rotary Cylinder Technical Specifications:
1. Gear-rack mechanism ensures smooth operation;
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
Installation protocol:
Apply Molykote G-5007 grease to shaft splines quarterly.
Maintain 0.3-0.5 MPa lubrication pressure when using external air-oilers.
Avoid side impact forces exceeding 30N during operation.
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ100 Technical Details
- Model: HRQ100
- Rotation angle: 0-190° adjustable (standard 90° preset)
- Torque output: 1.0 Nm (at 0.5 MPa)
- Operating pressure: 0.05–0.7 MPa
- Air port size: PT1/8 (G1/8 optional)
- Rotation speed: 0.5–1.5 sec/90° (air cushion adjustable)
- Weight: 0.82 kg
- Dimensions: 100mm(L) × 50mm(W) × 54mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Temperature range: -20℃ to 80℃
- Mounting pattern: ISO 6432 standard
- Repeat accuracy: ±0.5°
- Air consumption: 0.6 L/cycle (at 0.5 MPa)
- Protection rating: IP40
Precision rotary actuator featuring dual adjustable mechanical stops and built-in air cushioning. The hardened stainless steel shaft and double-bearing design ensure smooth rotation under lateral loads. Includes anti-rotation safety lock mechanism for vertical installations.
Industrial Applications:
- Part orientation flipping in assembly lines
- Indexing tables for CNC loading systems
- Valve actuation in process control
- Palletizer gripper rotation mechanisms
- Semiconductor wafer handling equipment
Installation protocol:
Apply Molykote G-5007 grease to shaft splines quarterly.
Maintain 0.3-0.5 MPa lubrication pressure when using external air-oilers.
Avoid side impact forces exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | HRQ100 |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | 100mm |
