Airtac HRQ Rotary Cylinder HRQ100A
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ100A Rotary Cylinder Specifications
- Model: HRQ100A
- Type: Double-acting rotary actuator
- Bore size: Ø100mm
- Rotation angle: 0-190° adjustable
- Torque output: 30-75 Nm (pressure-dependent)
- Operating pressure: 0.15-0.8 MPa
- Rotation speed: 50-150 rpm (air pressure dependent)
- Port size: 1/4" NPT (G1/4 optional)
- Weight: 3.8 kg ±2%
- Dimensions: 180mm(L) × 130mm(W) × 130mm(H)
- Seal material: HNBR with wear-resistant coating
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 recommended for maintenance)
- Mounting: Standard ISO 15552 mounting pattern
- Protection rating: IP54 (standard), IP67 optional
High-torque rotary cylinder with precision angular positioning, featuring adjustable mechanical stoppers for flexible rotation control. The hardened aluminum body with chrome-plated piston rod ensures durability in high-cycle applications. Requires filtered air (5-40μm) with 0.1-0.5% lubricant oil mist (ISO VG32 equivalent).
- Automated part indexing in assembly lines
- 90° workpiece flipping mechanisms
- Valve actuation in process control systems
- Robotic end-effector rotation
- Packaging machine lid closing mechanisms
Installation note:
Mount using M8 fasteners (30Nm tightening torque). Maintain 50mm clearance
around rotating parts. Perform initial 50-100 dry cycles before load operation.
Critical:
Do not exceed 1.0 MPa pressure. Avoid side-load impacts during rotation.
Install air cushioning kit (HRQ-CUSHION-100) for precision positioning applications.
| Property | Property Value |
|---|---|
| sku | HRQ100A |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 100mm |
