Airtac HRQ Rotary Cylinder HRQ10A
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ10A Technical Details
- Model: HRQ10A (Double-vane rotary actuator)
- Rotation angle: 0-190° adjustable (standard 90°±1°)
- Torque output: 0.98 N·m at 0.5 MPa
- Operating pressure: 0.1-0.8 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Piston diameter: φ32mm
- Rotation accuracy: ±0.2° (with adjustable stopper)
- Weight: 680g ±5% (without accessories)
- Dimensions: 76mm(W) × 76mm(H) × 62mm(D)
- Body material: Anodized aluminum alloy
- Seal type: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil)
- Mounting: 4x M5 threaded holes (8mm depth)
- Shock resistance: 15G acceleration (10ms duration)
Compact rotary actuator with precision angular control, featuring dual adjustable mechanical stoppers and wear-resistant bushing. The dual-vane design provides balanced torque output with <2° hysteresis. Includes built-in cushioning adjustment screws (M3×0.5) for smooth end-of-stroke deceleration. Requires 5μm filtered air supply with recommended 1-2 drops of oil per m³.
- 90° part flipping in conveyor systems
- Valve actuation in chemical processing
- Precision indexing in semiconductor handlers
- Clamping fixture rotation for CNC machining
- Camera/lens positioning in optical inspection
Installation guidelines:
Align mounting surface flatness within 0.05mm. Use spring washers on all
mounting screws (recommended torque 2.5N·m). Allow 15mm clearance for
rotation path. Perform initial 50 cycles at 0.2MPa for seating.
| Property | Property Value |
|---|---|
| sku | HRQ10A |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 10mm |
