Airtac HRQ Rotary Cylinder HRQ200
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Actuator HRQ200 Specifications
- Model: HRQ200
- Type: Rack-and-piston rotary actuator
- Rotation angle: 0-190° adjustable
- Torque output: 0.5-2.5 Nm (adjustable via air pressure)
- Operating pressure: 0.15-0.7 MPa
- Port size: 1/4" NPT (M5 optional)
- Rotation speed: 90° in 0.3-1.2 sec (air pressure dependent)
- Body material: Anodized aluminum alloy
- Shaft material: Stainless steel (SUS304)
- Seal material: NBR rubber
- Temperature range: -20℃ to 80℃
- Weight: 4.2 kg ±2%
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H)
- Mounting pattern: ISO 15552 compliant
- Position detection: Optional magnetic sensor slots
- Protection rating: IP54
The HRQ200 features dual-piston torque amplification with helical gear conversion, delivering precise angular positioning (±0.5° repeat accuracy). Its anti-backlash design maintains stability under variable loads, while the hardened steel shaft resists wear in high-cycle applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Robotic arm wrist rotation mechanisms
- Indexing tables in CNC machining centers
- 90° part flipping in assembly lines
- Valve actuation in process automation
- Camera/Sensor positioning systems
Installation note:
Lubricate guide rails monthly with ISO VG32 pneumatic oil. Avoid side-load exceeding 50N on shaft end.
For vertical mounting, install exhaust mist lubricator upstream. Maximum 10° misalignment tolerance.
| Property | Property Value |
|---|---|
| sku | HRQ200 |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | 200mm |
