Airtac HRQ Rotary Cylinder HRQ3
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AIRTAC HRQ Series Rotary Cylinder HRQ3 Technical Details
- Model: HRQ3
- Type: Compact rack-and-pinion rotary actuator
- Bore size: 32mm (standard)
- Rotation angle: 0-190° adjustable (default 180°±5°)
- Torque output: 0.6-1.2 N·m (at 0.5 MPa)
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5×0.8 (standard), G1/8 optional
- Mounting pattern: 4×M4 threaded holes (base mounting)
- Body material: Anodized aluminum alloy
- Seal type: NBR + PU combination
- Weight: 0.68 kg (dry, without accessories)
- Dimensions: 85mm(L) × 52mm(W) × 50mm(H)
- Cushioning: Adjustable end dampers
- Repeat accuracy: ±0.5°
Precision rotary actuator featuring helical gear mechanism for smooth angular motion. Dual-bearing design ensures minimal radial play during rotation. Includes magnetic slots for position sensor attachment (SM/SMF series compatible). Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality.
- 90° part flipping in assembly lines
- Workpiece orientation in CNC machine tool changers
- Valve actuation in food processing equipment
- Camera/sensor positioning in automated inspection systems
- Clamping arm rotation in plastic injection molds
Installation tip:
Lubricate pinion shaft with ISO VG32 hydraulic oil before initial use.
Avoid side-load exceeding 15N during operation. For vertical mounting,
ensure exhaust ports face downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | HRQ3 |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | <3> |
