Airtac HRQ Rotary Cylinder HRQ7
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ7 Technical Specifications
- Model: HRQ7
- Rotation angle: 0-190° adjustable (standard 90° or 180° preset)
- Torque output: 0.8 Nm (single acting) / 1.5 Nm (double acting)
- Operating pressure: 0.1-0.8 MPa
- Port size: 1/4" NPT (G1/8 optional)
- Rotation speed: 0.5-1.5 sec/90° (air pressure dependent)
- Weight: 1.2 kg ±5%
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H)
- Body material: Aluminum alloy (anodized finish)
- Piston material: Hardened stainless steel
- Seal type: NBR + PU composite seals
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (DOP-free grease)
- Mounting options: Front flange (ISO 15552 compatible)
- Position detection: Magnet embedded for sensor attachment
High-precision rotary actuator with dual piston torque amplification, featuring adjustable mechanical stops for angle customization. The HRQ7's twin-cylinder design delivers balanced rotational force with ±0.5° repeat accuracy, making it ideal for precision positioning tasks. Integrated shock absorbers minimize end-position vibration, while the through-shaft design allows optional position feedback device installation.
- Robotic arm joint articulation in assembly lines
- Index table rotation for CNC machine tooling
- 90° workpiece flipping in material handling systems
- Valve actuation in process control equipment
- Clamping mechanism rotation in fixture design
Installation tip:
Always install with 0.5-1mm axial clearance between cylinder and load connection.
Use M5x0.8 mounting screws (max torque 3.5 Nm). For vertical mounting,
install exhaust port downward to prevent condensate accumulation.
Maintenance note:
Replace seals every 500,000 cycles in normal operation.
Avoid angular overload beyond 200% rated torque to prevent gear train damage.
Requires 5μm filtered air with dew point -20℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | HRQ7 |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | 7 |
