Airtac MPEF Embedded Mounting Threaded Cylinder MPEF10X15
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF Embedded Threaded Cylinder MPEF10X15 Technical Details
- Series: MPEF (Compact Flange Embedded Series)
- Bore size: 10mm (0.39")
- Stroke: 15mm (0.59")
- Operating pressure: 0.05-0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50-800 mm/s
- Cushioning type: Fixed rubber buffer
- Thread type: M5×0.8 embedded mounting
- Port size: M5×0.8 (Dual Rc1/8 optional)
- Material: Aluminum alloy body, CRMo steel piston rod
- Seal material: NBR + PU hybrid seals
- Weight: 72g ±2g (excluding accessories)
- Dimensions: 46mm(L) × 28mm(W) × 28mm(H)
- Protection class: IP54 (standard), IP67 (optional wiper)
- Lubrication: Pre-lubricated (DOP mist lubrication compatible)
Ultra-compact embedded cylinder with integrated mounting threads, designed for space-constrained automation systems. Features dual-port configuration for flexible piping and anti-rotation piston rod for precise positioning. Corrosion-resistant anodized surface treatment enables operation in humid environments (RH ≤95%).
- PCB handling robots for micro-component placement
- Lens polishing machine clamping mechanisms
- 3D printer filament feed tension control
- Medical analyzer reagent arm positioning
- Semiconductor wafer cassette elevators
Installation protocol:
Use torque-controlled installation (1.2-1.5N·m) with Loctite 243 thread locker.
Maintain 0.5mm minimum clearance between cylinder body and mounting surface
for thermal expansion. Lubricate piston rod weekly in high-cycle applications (>500CPM).
| Property | Property Value |
|---|---|
| sku | MPEF10X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
