Airtac MPEF Embedded Mounting Threaded Cylinder MPEF12X15
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF12X15 Buried Mounting Threaded Cylinder Specifications
- Model: MPEF12X15
- Type: Single-acting spring return (buried thread installation)
- Bore size: 12mm
- Stroke: 15mm
- Thread type: M5X0.8 embedded mounting thread
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer
- Port size: M5×0.8 (standard) / G1/8 optional
- Mounting orientation: Any direction
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile Butadiene Rubber)
- Weight: 180g ±5%
- Dimensions:
- Body length: 50mm
- Total stroke length: 65mm
- Mounting flange diameter: 22mm
- Port center distance: 16mm
Ultra-compact cylinder featuring flush-mounted thread design for space-constrained automation systems. The through-hole structure allows direct mounting without additional brackets, with corrosion-resistant surface treatment for harsh environments. Requires 0.1-20μm filtered air with ISO 8573-1 purity class.
- PCB handling robots in electronics assembly
- Precision clamping in optical lens production
- Valve actuation in medical analyzers
- Miniature sorting mechanisms in logistics automation
- Semiconductor wafer positioning systems
Installation notes:1. Use 2.5-3.5Nm torque for thread fastening
2. Maintain 0.5mm minimum clearance around cylinder body
3. Lubricate with ISO VG32 hydraulic oil if used below -5℃
4. Avoid side loads exceeding 5N during operation
| Property | Property Value |
|---|---|
| sku | MPEF12X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
