Airtac MPEF Embedded Mounting Threaded Cylinder MPEF8X10
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF8X10 Built-in Threaded Cylinder Specifications
- Model: MPEF8X10
- Type: Double-acting embedded thread cylinder
- Bore size: 8mm (Φ8)
- Stroke: 10mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port thread: M5x0.8 (standard)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Cushion type: Rubber buffer (adjustable)
- Mounting type: Embedded screw-in (M4 mounting holes)
- Weight: 0.12kg ±5%
- Dimensions: 70mm(L) × 20mm(W) × 20mm(H)
- Max theoretical thrust: 4.2kgf @0.63MPa
- Max speed: 500mm/s
- Protection rating: IP54 (standard)
Ultra-compact threaded cylinder designed for space-constrained installations requiring precise linear motion. Features corrosion-resistant construction with precision honed inner bore (Ra≤0.2μm) for smooth operation. Integrated mounting threads allow direct embedding into machinery structures without additional brackets.
- Semiconductor wafer handling robots
- Precision valve actuation in medical devices
- Miniature clamping mechanisms in CNC fixtures
- Optical lens positioning systems
- Laboratory automation sample handlers
Installation guidelines:
Apply thread locker (Loctite 243 recommended) on M4 mounting screws.
Ensure alignment tolerance ≤0.05mm during embedding. Lubricate with ISO VG32
hydraulic oil before initial use. Avoid side loads exceeding 2N·m.
Critical note:
Do not exceed 0.8MPa working pressure. Install air filter (5μm+40μm dual-stage)
upstream. For vertical mounting, use anti-vibration pads on both ports.
| Property | Property Value |
|---|---|
| sku | MPEF8X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <8mm> |
| Stroke | <10mm> |
