Airtac MPG Standard Panel Mount Cylinder MPG10X10SN
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Series Standard Panel Cylinder MPG10X10SN Technical Details
- Model: MPG10X10SN
- Bore size: 10mm (0.39")
- Stroke: 10mm (0.39")
- Action type: Double-acting
- Mounting style: Panel mount with front flange
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Operating pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable rubber cushion (both ends)
- Piston rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 0.12 kg (0.26 lbs)
- Dimensions (L×W×H): 42×20×30 mm (1.65×0.79×1.18 in)
- ISO standard: 6432 (mounting dimensions compliant)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Lubrication: Pre-lubricated (maintenance-free operation)
Ultra-compact panel cylinder designed for space-constrained automation systems. Features dual anti-rotation guides for precise linear motion control and a wear-resistant piston rod coating. The built-in magnet in piston enables position sensing compatibility (sensor not included). Optimized for vertical or horizontal mounting in clean environments.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in optical lens production
- Valve actuation in analytical instruments
- Paper feed mechanisms in desktop printers
- Micro-part positioning in watch manufacturing
Installation guidelines:
Ensure mounting surface flatness ≤0.1mm. Use dynamic load calculations for strokes exceeding 50% of catalog maximum.
For optimal performance, maintain air supply dew point 15℃ below ambient temperature.
Avoid side loads exceeding 0.3N·m.
For pulsating applications (>5Hz), consult factory for reinforced mounting options.
| Property | Property Value |
|---|---|
| sku | MPG10X10SN |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Non-threaded |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
