Airtac MPG Standard Panel Mount Cylinder MPG10X20
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Series Panel-Mount Cylinder MPG10X20 Specifications
- Model: MPG10X20
- Type: Single-acting spring return (panel mount)
- Bore diameter: 10mm
- Stroke: 20mm
- Operating pressure: 0.05–0.8 MPa
- Port size: M5x0.8 (standard) / G1/8 optional
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (nitrile) with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Piston speed: 50–700 mm/s
- Mounting: Front panel screw mounting (4xM3 threaded holes)
- Weight: 98g ±2g
- Dimensions:
- Body length: 62mm
- Total extended length: 82mm (stroke included)
- Panel cutout: 35mm(W) × 12mm(H)
- Mounting depth: 25mm
- Protection rating: IP54 (standard sealing)
Ultra-compact panel-mount cylinder designed for space-constrained automation systems. Features precision-ground rod and anodized aluminum construction for smooth operation in high-cycle applications. Includes dual-position sensor slots (inductive sensor compatible) for position feedback integration.
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical equipment
- Clamping mechanisms in SMT pick-and-place machines
- Actuation of small shutters in optical inspection systems
- Precision paper feed mechanisms in POS printers
Installation note:
Use 0.3-0.5MPa dry air with 5μm filtration. Lubricate with ISO VG32 turbine oil
if non-lubricated operation required. Avoid side load exceeding 2N. For vertical
mounting, consider adding external guide mechanism for stroke stability.
| Property | Property Value |
|---|---|
| sku | MPG10X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
