Airtac MPG Standard Panel Mount Cylinder MPG10X25
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X25 Technical Details
- Model: MPG10X25
- Type: Single-acting spring return (Push type)
- Bore size: 10mm
- Stroke: 25mm
- Operating pressure: 0.15–0.8 MPa
- Operating medium: Clean air (Lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Mounting type: Front panel mounting with 4x M3 threaded holes
- Port size: M5x0.8 (G1/8 adapter optional)
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber (FDA compliant options available)
- Weight: 98g ±2g
- Dimensions: 42mm(W) × 25mm(H) × 56mm(L) (Excluding rod extension)
- Protection class: IP54 (Standard), IP67 (Optional wiper upgrade)
- Max theoretical force: 6.28N at 0.5MPa
- Response time: ≤0.15s at rated pressure
Ultra-compact panel cylinder engineered for space-constrained automation systems. Features dual sealing structure with self-lubricating guide bushings for maintenance-free operation. The precision-ground piston rod and anti-rotation design ensure stable linear motion, while the modular construction allows easy integration with sensors and accessories.
- PCB handling robots - component insertion/pressing
- Medical device actuators - sample tray positioning
- Semiconductor wafer processing equipment
- Automated test fixture clamping mechanisms
- Compact labeling machine pushers
- Precision optical alignment systems
Installation best practices:
Maintain ≤0.5mm panel thickness tolerance for secure mounting.
Use wave washers to prevent loosening under vibration.
For vertical installations, orient exhaust ports downward to prevent condensation accumulation.
| Property | Property Value |
|---|---|
| sku | MPG10X25 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
