Airtac MPG Standard Panel Mount Cylinder MPG10X25SN
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Series Standard Panel Cylinder MPG10X25SN Technical Details
- Model Code: MPG10X25SN
- Series: MPG (Panel Mount Standard Type)
- Bore Size: 10mm
- Stroke: 25mm
- Operating Pressure: 0.05-0.9 MPa
- Cushioning Type: Fixed rubber buffer (both ends)
- Mounting Style: Front panel mounting with 4x M3 screws
- Port Size: M5×0.8 (Rc1/8 adaptor optional)
- Piston Material: Aluminum alloy hard anodized
- Rod Material: Stainless steel SUS304
- Seal Type: NBR seals standard (PU optional)
- Temperature Range: -20℃ to 80℃
- Weight: 0.23 kg (bare cylinder without accessories)
- Dimensions:
- Body Length: 85mm (excluding rod)
- Extended Length: 110mm (full stroke)
- Panel Cutout: 10.5mm diameter
- Mounting Flange: 25×25mm square base
- Protection Class: IP54 (standard sealing)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if required)
Compact panel-mounted pneumatic cylinder designed for precise linear motion in confined spaces. Features corrosion-resistant construction with dual guide rods for enhanced stability. The through-hole piston rod design allows for optional magnetic sensing. Ideal for clean environments due to minimal particle generation.
- Semiconductor wafer handling robots
- Precision dispensing equipment valves
- Optical lens positioning mechanisms
- Laboratory automation sample handlers
- Medical device actuator systems
Installation note:
Maintain 0.5mm clearance around piston rod during alignment.
For vertical mounting, specify "MPG10X25SN-V" variant with reinforced rod lock nut.
| Property | Property Value |
|---|---|
| sku | MPG10X25SN |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Non-threaded |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
