Airtac MPG Standard Panel Mount Cylinder MPG10X35
2. High-precision piston rod guidance eliminates the need for external lubrication;
3. Advanced rubber encapsulation process on rear cover ensures superior cushioning performance;
4. Multiple mounting configurations and optional accessories ensure flexible installation solutions tailored to client needs;
5. Optional magnetic version with integrated position sensing capability;
6. Pre-machined sensor slot on barrel enables convenient magnetic proximity sensor installation;
7. Comprehensive bore size selection accommodates diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPG
AirTAC MPG Standard Panel Cylinder MPG10X35 Technical Details
- Model: MPG10X35
- Bore size: Ø10mm
- Stroke: 35mm (Customizable: 10-300mm)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Mounting type: Front panel flange (ISO 15552 compatible)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Repeat accuracy: ±0.2mm
- Protection rating: IP40
- Weight: 0.25kg (excluding accessories)
- Dimensions:
- Length (retracted): 102mm
- Width (flange): 30mm
- Height (max extended): 137mm
Precision-engineered compact cylinder with dual guide rods for enhanced lateral stability. Features low-friction seals and wear-resistant construction, optimized for high cycle rates (up to 1,500 cycles/hour). Requires ISO VG32 hydraulic oil lubrication for optimal performance. Compatible with magnetic sensors (sensor groove included).
- PCB handling in SMT assembly lines
- Precision clamping in optical lens production
- Valve actuation in medical analyzers
- Automated sorting gates in packaging systems
- Test fixture positioning in automotive QA
Installation tip:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use torque-controlled tightening (1.2-1.5N·m) on mounting bolts to prevent housing distortion.
| Property | Property Value |
|---|---|
| sku | MPG10X35 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 35mm |
