Airtac MPGH Hinge Mount Type Cylinder MPGH10X15S
$27.88
Regular price
$35.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MPGH10X15S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The MPGH Hinge-Mounted Cylinder Series by AIRTAC features:
1. Compact design with minimized footprint and lightweight construction for space-efficient integration;
2. High-precision piston rod guidance ensuring stable operation without external lubrication;
3. Advanced rubber-cushioned rear cap technology for superior shock absorption performance;
4. Flexible mounting configurations with customer-selectable accessories for versatile installation;
5. Optional magnet-embedded models enabling position feedback via magnetic sensors;
6. Pre-machined sensor slots on barrel for tool-free magnetic switch installation;
7. Multiple standardized bore sizes available to meet diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPGH
Installation note:
Apply thread-locking compound to hinge screws (M4x10, torque 1.2N·m).
Maintain 0.5mm clearance between cylinder body and adjacent surfaces during swing motion.
Lubricate pivot point with silicone grease every 500,000 cycles.
AirTAC MPGH10X15S Hinge-Mount Cylinder Specifications
- Model: MPGH10X15S
- Type: Compact hinge-mounted single-acting cylinder
- Bore size: 10mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 70℃
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber bumper
- Mounting: Integrated M4 threaded hinge with ±5° alignment tolerance
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Material:
- Barrel: Hard anodized aluminum alloy
- Piston rod: Chrome-plated steel
- Seals: NBR (Nitrile) standard, optional Fluorocarbon (-20℃~150℃)
- Weight: 0.23 kg (excluding accessories)
- Dimensions:
- Length: 82mm (min. retracted length)
- Width: 34mm (mounting hinge span)
- Height: 40mm (barrel diameter + mounting ears)
- ISO standard: 6431 compliant
- Position detection: Pre-drilled slots for magnetic sensor (SM series compatible)
Ultra-compact hinge-mount cylinder designed for space-constrained oscillating mechanisms. Features self-lubricating guide bushings and anti-rotation pin for precise angular movement. Requires 5μm filtered air (ISO 8573-1 class 3) with lubrication (ISO VG32 recommended).
Typical Applications:
- Semiconductor wafer handling arms
- Robotic gripper jaw actuation
- Medical device lid closure mechanisms
- Conveyor diverter flap control
- Precision valve actuation systems
Installation note:
Apply thread-locking compound to hinge screws (M4x10, torque 1.2N·m).
Maintain 0.5mm clearance between cylinder body and adjacent surfaces during swing motion.
Lubricate pivot point with silicone grease every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | MPGH10X15S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
