Airtac MPGH Hinge Mount Type Cylinder MPGH10X25S
$28.81
Regular price
$36.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MPGH10X25S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The MPGH Hinge-Mounted Cylinder Series by AIRTAC features:
1. Compact design with minimized footprint and lightweight construction for space-efficient integration;
2. High-precision piston rod guidance ensuring stable operation without external lubrication;
3. Advanced rubber-cushioned rear cap technology for superior shock absorption performance;
4. Flexible mounting configurations with customer-selectable accessories for versatile installation;
5. Optional magnet-embedded models enabling position feedback via magnetic sensors;
6. Pre-machined sensor slots on barrel for tool-free magnetic switch installation;
7. Multiple standardized bore sizes available to meet diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPGH
Installation tip:
Align hinge axis parallel to mounting surface. Apply lithium soap grease
to pivot points during assembly. Max allowable angular misalignment: ±3°.
AirTAC MPGH Hinge-Mounted Cylinder MPGH10X25S Technical Details
- Model: MPGH10X25S
- Type: Compact hinge-mounted single-acting cylinder (spring return)
- Bore size: 10mm
- Stroke: 25mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable elastic cushion
- Mounting: Integrated hinge bracket (270° adjustable)
- Material: Aluminum alloy body, stainless steel hinge pin
- Seal type: NBR seals (oil-resistant)
- Weight: 0.22kg (excluding accessories)
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H) (at neutral position)
- Rod thread: M5x0.8 external thread
- Max lateral load: 5N
- Piston speed: 50–500mm/s
Ultra-compact swing cylinder with integrated pivot joint, designed for confined spaces requiring angular motion. Features anti-rotation guide slots and dual lubrication ports. The zinc-nickel plated hinge mechanism withstands 50,000+ cycles at rated load.
Ideal Applications:
- Precision door/hatch actuation in lab equipment
- Sorting gate control in packaging lines
- Micro-positioning in semiconductor handlers
- Vending machine mechanisms
- Robotic tool changer interfaces
Installation tip:
Align hinge axis parallel to mounting surface. Apply lithium soap grease
to pivot points during assembly. Max allowable angular misalignment: ±3°.
| Property | Property Value |
|---|---|
| sku | MPGH10X25S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
