Airtac MPGH Hinge Mount Type Cylinder MPGH10X35
$26.48
Regular price
$33.98
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MPGH10X35
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The MPGH Hinge-Mounted Cylinder Series by AIRTAC features:
1. Compact design with minimized footprint and lightweight construction for space-efficient integration;
2. High-precision piston rod guidance ensuring stable operation without external lubrication;
3. Advanced rubber-cushioned rear cap technology for superior shock absorption performance;
4. Flexible mounting configurations with customer-selectable accessories for versatile installation;
5. Optional magnet-embedded models enabling position feedback via magnetic sensors;
6. Pre-machined sensor slots on barrel for tool-free magnetic switch installation;
7. Multiple standardized bore sizes available to meet diverse application requirements.
Category: Multi-position Cylinders | Brand: AIRTAC | Series: MPGH
Installation tips:
Align hinge pivot axis parallel to rotation plane. Use Loctite 243 on mounting screws.
For vertical installations, add a 0.3mm shim under lower hinge plate to compensate for thermal expansion.
Operation notes:
Maintain air supply dew point -20℃ below ambient. Avoid side loads exceeding 3N·m.
Lubricate pivot bushings every 500km stroke travel using MIL-PRF-6085 grease.
AirTAC MPGH Hinge-Mounted Cylinder MPGH10X35 Technical Details
- Model: MPGH10X35
- Series: MPGH (Compact Hinge Mount)
- Bore size: 10mm
- Stroke: 35mm (±1mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Hinged bracket (ISO 15552 compatible)
- Port thread: M5×0.8 (standard) / G1/8 optional
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Max speed: 500 mm/s
- Weight: 0.25 kg (excluding mounting accessories)
- Dimensions (L×W×H): 95mm × 25mm × 30mm (at mid-stroke)
- Rod thread: M5×0.5 (external)
- Protection rating: IP54 (standard sealing)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
A space-saving hinge-mounted cylinder designed for angular motion applications. Features dual adjustable air cushions for smooth end-of-stroke deceleration and reinforced rod bearings for lateral load resistance. The modular design allows 180° hinge rotation adjustment without disassembly.
Ideal for:
- Rotating clamps in PCB assembly lines
- Index table positioning systems
- Medical bed articulation mechanisms
- Packaging machine flap folding units
- Solar panel tracking adjusters
- Automotive welding fixture rotations
Installation tips:
Align hinge pivot axis parallel to rotation plane. Use Loctite 243 on mounting screws.
For vertical installations, add a 0.3mm shim under lower hinge plate to compensate for thermal expansion.
Operation notes:
Maintain air supply dew point -20℃ below ambient. Avoid side loads exceeding 3N·m.
Lubricate pivot bushings every 500km stroke travel using MIL-PRF-6085 grease.
| Property | Property Value |
|---|---|
| sku | MPGH10X35 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 35mm |
