Airtac MPGH Hinge Mount Type Cylinder MPGH10X35S
AirTAC MPGH Hinge Mount Cylinder MPGH10X35S Specifications
- Model: MPGH10X35S
- Type: Single-acting spring return (hinge-mounted)
- Bore size: 10mm
- Stroke: 35mm (±1mm tolerance)
- Operating pressure: 0.15–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard dual ports)
- Cushioning: Elastic buffer with adjustable end caps
- Mounting type: Integrated hinge bracket (M4 screw holes)
- Material: Aluminum alloy body, NBR seals
- Weight: 0.65kg (including mounting hardware)
- Dimensions: 110mm(L) × 34mm(W) × 24mm(H)
- Rod thread: M5x0.8 external thread
- Max theoretical force: 70.7N @ 0.9MPa
- Repeat positioning accuracy: ±0.5mm
- ISO standard: 6432 compliant
Ultra-compact hinge-mount cylinder designed for space-constrained rotational applications. Features 360° adjustable hinge bracket for precise angular positioning. The chrome-plated piston rod and dual sealing system ensure durability in high-cycle operations (up to 1.5 million cycles). Includes built-in auto-lubrication design for reduced maintenance.
- Robotic arm joint actuation in electronics assembly
- Medical equipment lid closure mechanisms
- Rotary clamping fixtures for CNC machines
- Compact packaging machine diverters
- Semiconductor wafer handling systems
Installation note:
Mount using M4x8mm screws (max torque 1.2N·m). Ensure hinge axis alignment within ±2°
deviation. Lubricate pivot point with ISO VG32 hydraulic oil before initial operation.
| Property | Property Value |
|---|---|
| sku | MPGH10X35S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 35mm |
