Airtac MPGH Hinge Mount Type Cylinder MPGH10X5
AirTAC MPGH Hinge-Mounted Cylinder MPGH10X5 Specifications
- Model: MPGH10X5
- Type: Double-acting hinge-mounted cylinder
- Bore size: 10 mm
- Stroke: 50 mm (X5 designation)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Port thread: M5×0.8 (standard) / G1/8 optional
- Material: Aluminum alloy cylinder tube, chromium-plated piston rod
- Seal material: NBR (nitrile rubber)
- Mounting style: Integrated hinge bracket with M4 mounting holes
- Weight: 0.25 kg (without accessories)
- Dimensions: 78mm(L) × 25mm(W) × 25mm(H) (excluding rod extension)
- Max theoretical force: 7.85 N at 0.1 MPa
- Piston speed: 50–700 mm/s
- Protection rating: IP54 (standard sealing)
A compact hinge-mounted cylinder optimized for angular motion applications. Features precision-machined guide grooves for stable rotation (±3° tolerance) and an anti-rotation pin for load alignment. The through-hole piston rod design allows for bidirectional force transmission. Pre-lubricated with Grease No. 2 (ISO VG32 equivalent).
- Clamping arms in semiconductor wafer handling systems
- Rotary indexing tables in packaging machinery
- Valve actuation in cleanroom environments
- Precision flipping mechanisms for PCB assembly
- Medical device positioning systems
Installation note:
Mounting surface flatness must be ≤0.1mm/m. Use dynamic load calculations when
angular acceleration exceeds 0.5 rad/s². Lubricate hinge pin every 500km of
cumulative travel. Avoid side loads exceeding 2N·m.
| Property | Property Value |
|---|---|
| sku | MPGH10X5 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
