Airtac MU Mini Free Mount Cylinder MU10X25SB
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU10X25SB Compact Free Mount Cylinder Specifications
- Model: MU10X25SB
- Type: Double-acting cylinder with magnetic piston
- Bore size: 10mm (0.39")
- Stroke: 25mm (0.98")
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber buffers
- Mounting style: Free mounting (no fixed flange)
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Magnetic sensor compatibility: Built-in magnet for proximity switch detection
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 0.12kg (approx.)
- Dimensions:
- Total length: 70mm (2.76")
- Body diameter: Φ20mm (0.79")
- Mounting hole spacing: 30mm (1.18") center-to-center
- Rod end thread: M4x0.7
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features dual anti-rotation design for stable linear motion and integrated mounting slots (4.5mm width) for flexible installation. The corrosion-resistant construction allows operation in mildly harsh environments when paired with proper air filtration (5μm recommended).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in medical device manufacturing
- Carton flap control in packaging machinery
- Laboratory automation sample positioning
- Semiconductor wafer processing equipment
Installation guidelines:
Maintain ≤0.5mm alignment tolerance during mounting. Lubricate with ISO VG32 turbine oil
before initial use. For vertical installations exceeding 45° angle, consider adding
external guide mechanisms to prevent side load. Maximum permissible lateral load: 2N.
| Property | Property Value |
|---|---|
| sku | MU10X25SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
